1.Applikazzjoni (kejbil ABC):
Il-kejbil ABC huwa adattat għat-trażmissjoni tal-linja u d-distribuzzjoni tal-linja ta 'vultaġġ nominali 0.6/1KV u oħrajn. Huwa użat ħafna f'bini għoli, żona ta' żvilupp li jivvjaġġa u żona rurali jew post ieħor l-ispiża tan-netwerk taħt l-art hija għalja.
2.Standards(kejbil ABC):
Dan il-kejbil ABC huwa manifatturat skont Standards Nazzjonali Ċiniżi, IEC, SANS 1418, ASTM, NF C33-209 u eċċ fuq talba.
3.Kostruzzjoni tal-Cable(kejbil ABC):
ABC Cable (Aerial Bundled Cable) huma wajers tal-aluminju tal-Grad EC stranded b'mod konċentriku, iżolati jew b'polyethylene cross linked reżistenti għat-temp iswed (XLPE) jew polyethylene (PE). L-insulazzjoni tal-konduttur hija mmarkata bi ħniek lonġitudinali għall-identifikazzjoni tal-fażi.
4.Parametru(kejbil ABC):
Cable ABC (Kejbil miġbura mill-ajru) | ||||||
SPEC. mm² | Struttura tal-Konduttur (AL Kumpatt) (Nru./mm) | Materjal ta 'insulazzjoni | Ħxuna tal-iżolament (mm) | Appross. Dijametru Ġenerali (mm) | Appross. Piż (kg/km) | Ippakkjar Meters għal kull Drum |
2x16 | 7/1.72 | XLPE (HDPE) | 1.2 | 14.6 | 131.4 | 250-4000m |
2x25 | 7/2.15 | 1.2 | 16.8 | 189 | 250-4000m | |
2x35 | 7/2.54 | 1.4 | 19.8 | 264.5 | 250-3500m | |
2x50 | 7/2.92 | 1.4 | 22.6 | 344.1 | 250-3000m | |
2x70 | 19/2.15 | 1.4 | 25.6 | 470 | 250-3000m | |
2x95 | 19/2.54 | 1.6 | 29.8 | 645.5 | 250-3000m | |
3x16 | 7/1.72 | 1.2 | 15.7 | 197.1 | 250-4000m | |
3x25 | 7/2.15 | 1.2 | 18.1 | 283.5 | 250-3500m | |
3x35 | 7/2.54 | 1.4 | 21.3 | 396.7 | 250-3500m | |
3x50 | 7/2.92 | 1.4 | 24.3 | 516.2 | 250-3000m | |
3x70 | 19/2.15 | 1.4 | 27.6 | 705.1 | 250-3000m | |
3x95 | 19/2.54 | 1.6 | 32.1 | 968.2 | 250-3000m | |
4x16 | 7/1.72 | 1.2 | 17.6 | 262.9 | 250-3500m | |
4x25 | 7/2.15 | 1.2 | 20.3 | 378 | 250-3500m | |
4x35 | 7/2.54 | 1.4 | 23.9 | 528.9 | 250-3000m | |
4x50 | 7/2.92 | 1.4 | 27.3 | 688.3 | 250-3000m | |
4x70 | 19/2.15 | 1.4 | 30.9 | 940.1 | 250-3000m | |
4x95 | 19/2.54 | 1.6 | 36 | 1291 | 250-3000m | |
Cable ABC (Kejbil miġbura mill-ajru) | |||||||
SPEC. mm² | Struttura tal-Konduttur | Materjal ta 'insulazzjoni | Ħxuna tal-iżolament (mm) | Appross. Dijametru Ġenerali (mm) | Appross. Piż (kg/km) | Ippakkjar Meters għal kull Drum | |
Fażi (AL Kumpatt) | Newtrali (Liga) | ||||||
(Nru./mm) | Aluminju (Nru./mm) | ||||||
1x16 flimkien ma '1x16 | 7/1.72 | 7x1.72 | XLPE (HDPE) | 1.2 | 12.5 | 110.1 | 250-4000m |
1x25 flimkien ma '1x25 | 7/2.15 | 7/2.15 | 1.2 | 14.9 | 163.9 | 250-4000m | |
1x35 flimkien ma '1x35 | 7/2.54 | 7/2.54 | 1.4 | 17.5 | 229 | 250-3500m | |
1x50 flimkien ma '1x50 | 7/2.92 | 7/2.92 | 1.4 | 20.1 | 300 | 250-3000m | |
1x70 flimkien ma '1x70 | 19/2.15 | 19/2.15 | 1.4 | 23.6 | 423.2 | 250-3000m | |
1x95 flimkien ma '1x95 | 19/2.54 | 19/2.54 | 1.6 | 27.6 | 585.4 | 250-3000m | |
2x16 flimkien ma '1x16 | 7/1.72 | 7/1.72 | 1.2 | 14.2 | 175.8 | 250-4000m | |
2x25 flimkien ma '1x25 | 7/2.15 | 7/2.15 | 1.2 | 16.7 | 258.4 | 250-3500m | |
2x35 flimkien ma '1x35 | 7/2.54 | 7/2.54 | 1.4 | 19.7 | 361.2 | 250-3500m | |
2x50 flimkien ma '1x50 | 7/2.92 | 7/2.92 | 1.4 | 22.5 | 472.1 | 250-3000m | |
2x70 flimkien ma '1x70 | 19/2.15 | 19/2.15 | 1.4 | 26.1 | 658.3 | 250-3000m | |
2x95 flimkien ma '1x95 | 19/2.54 | 19/2.54 | 1.6 | 30.5 | 908.2 | 250-3000m | |
3x16 flimkien ma '1x16 | 7/1.72 | 7/1.72 | 1.2 | 16.3 | 241.5 | 250-3500m | |
3x25 flimkien ma '1x25 | 7/2.15 | 7/2.15 | 1.2 | 19.1 | 353.6 | 250-3500m | |
3x35 flimkien ma '1x35 | 7/2.54 | 7/2.54 | 1.4 | 22.5 | 493.5 | 250-3000m | |
3x50 flimkien ma '1x50 | 7/2.92 | 7/2.94 | 1.4 | 25.7 | 644.1 | 250-3000m | |
3x70 flimkien ma '1x70 | 19/2.15 | 19/2.15 | 1.4 | 29.7 | 895.2 | 250-3000m | |
3x95 flimkien ma '1x95 | 19/2.54 | 19/2.54 | 1.6 | 34.6 | 1233.5 | 250-3000m | |
5.Pakkett: Esportazzjoni tnabar tal-injam (kejbil ABC):
